A449 Bolts

ASTM A449 Bolts Specifications

This ASTM A449 Bolts specification covers quenched and tempered, medium strength hex cap screws, headed bolts, rods and nuts from 1/4” to 3” in diameter. ASTM A449 products are manufactured from medium carbon or alloy steel and are heat treated to acheive their required mechanical properties. ASTM A449 is very similar to ASTM A325 in chemistry and strength but covers a wider range of diameters.

A449 Bolts

A449 Fasteners are designated by type denoting chemical composition as follows:

TYPE DESCRIPTION
TYPE 1 Plain Carbon Steel, Carbon Boron Steel, Alloy Steel, Alloy Boron Steel
TYPE 2 **Withdrawn in 2003**
TYPE 3 Weathering Steel



A449 CHEMICAL PROPERTIES

Type 1 Bolts
Element Carbon Steel Carbon Boron Steel Alloy Steel Alloy Boron Steel
Carbon 0.30 – 0.52% 0.30 – 0.52% 0.30 – 0.52% 0.30 – 0.52%
Manganese, min 0.60% 0.60% 0.60% 0.60%
Phosphorus, max 0.04% 0.04% 0.04% 0.04%
Sulfur, max 0.05% 0.05% 0.04% 0.04%
Silicon 0.15-0.30% 0.10 – 0.30% 0.15 – 0.35% 0.15 – 0.35%
Boron 0.0005 – 0.003% 0.0005 – 0.003%



Type 3 Bolts
Carbon 0.33 – 0.40% 0.38 – 0.48% 0.15 – 0.25% 0.15 – 0.25% 0.20 – 0.25% 0.20 – 0.25%
Manganese 0.90 – 1.20% 0.70 – 0.90% 0.80 – 1.35% 0.40 – 1.20% 0.60 – 1.00% 0.90 – 1.20%
Phosphorus 0.035% max 0.06 – 0.12% 0.035% max 0.035% max 0.04% 0.04%
Sulfur, max 0.04% 0.04% 0.04% 0.04% 0.04% 0.04%
Silicon 0.15 – 0.35% 0.30 – 0.50% 0.15 – 0.35% 0.25 – 0.50% 0.15 – 0.35% 0.15 – 0.35%
Copper 0.25 – 0.45% 0.20 – 0.40% 0.20 – 0.50% 0.30 – 0.50% 0.30 – 0.60% 0.20 – 0.40%
Nickel 0.25 – 0.45% 0.50 – 0.80% 0.25 – 0.50% 0.50 – 0.80% 0.30 – 0.60% 0.20 – 0.40%
Chromium 0.45 – 0.65% 0.50 – 0.75% 0.30 – 0.50% 0.50 – 1.00% 0.60 – 0.90% 0.45 – 0.65%
Vanadium 0.020% min
Molybdenum 0.06% max 0.10% max
Titanium 0.05% max



A449 MECHANICAL REQUIREMENTS

Size    Tensile, ksi       Yield, ksi       Elong. %, min     RA %, min
1/4” – 1”           120 min         92 min                  14            35
1-1/8” – 1-1/2”           105 min         81 min                  14            35
1-5/8” – 3”             90 min         58 min                  14            35

See Also: ASTM A449 Specifications on ASTM.org.
